High Low Voltage Fireproof 1000A 1250A Aluminium Busbar Channel Waterproof Casting

  • 1
  • 2

Certification : ISO9001

Place of Origin : Langfang, Hebei, China

Rated Current : 200 - 6300 A

Application : Outdoor, Industrial, Electric Power Transmission

Surface treatment : Housing aluminum alloy/conductor TMY copper

Frequency : 50-60Hz

Degree of protection : IP54/IP66

Rated Voltage : 690 V, 1000V

Working Temperature : -40℃~+80℃

Rated frequency : 50Hz--60Hz

Brand Name : BZIDA

MOQ : 50 meters

Packaging Details : Export standard compliant

Delivery Time : 30 days

Payment Terms : 30% prepayment, full payment upon delivery

Supply Ability : 3000 meters per month

Contact Now

High-Low Voltage Fireproof 1000A 1250A Aluminium Busbar Channel Waterproof Casting Product Busway

Product Description:

Busbar trunking uses copper bars or aluminum as conductors, with a large current capacity and good electrical and mechanical properties. In addition, metal trunking is used as the shell, which has the advantages of non combustion, high safety and reliability, and long service life. Compared with traditional power distribution, the equipment occupies a significantly reduced area and has a beautiful appearance, which is very advantageous for the construction and power distribution of large buildings.

In summary, bus ducts have the following characteristics: 1. The current capacity can be very large; 2. The voltage drop is very small; 3. Strong short-circuit load capacity; 4. High reliability and long service life; 5. High safety; 6. The equipment of the power distribution system can be added or changed freely; 7. Small external dimensions; 8. Lightweight and easy to operate; 9. The connection is very simple (just like connecting water pipes, connecting them into a system through tees, elbows, and other joints) as shown in the following figure; 10. Simple construction and inspection; 11. It has a modern aesthetic.

Features:

1. Bus ducts use copper or aluminum as conductors, which have extremely high conductivity and can efficiently transmit large currents, meeting the needs of large-scale power transmission.

2. The bus duct has a compact structure and small volume, which can provide higher transmission capacity in limited space. Greatly saving installation space and reducing the cost of electrical engineering.

3. The maintenance of bus ducts is relatively simple and convenient. The connection part adopts bolt fastening or plug-in design, which is easy to disassemble and replace.

Technical Parameters:

Implementation Standard
IEC/EN 60 439-6, GB7251.1
System
Three-phase three-wire, Three-phase four-wire, Three-phase five-wire (with separate PE busbar), Three-phase five-wire (with casing
as PE)
Rated Insulation Voltage (Ui)
AC/ DC 1000V/800V
Rated Operating Voltage (Ue)
AC1000V/690V
Rated Frequency
50/60Hz
Enclosure Material/Surface Treatment
Aluminum Alloy / Powder Coating
Conductor Material
Tin-Plated Copper or/Tin-Plated Copper-Clad Aluminum/Aluminum
Voltage Category / Pollution Degree
III/3
Horizontal Mounting Spacing
≤ 2m

High Low Voltage Fireproof 1000A 1250A Aluminium Busbar Channel Waterproof Casting

High Low Voltage Fireproof 1000A 1250A Aluminium Busbar Channel Waterproof Casting

High Low Voltage Fireproof 1000A 1250A Aluminium Busbar Channel Waterproof Casting

FAQ:

1.Are you a trade company or a manufacturer?

Baizida Electrical Equipment Co., Ltd is a production and sales-oriented enterprise focusing on the production of power equipment, integrating design, research and development, manufacturing and technical services.

2.What are the main products of your company?

Our company specializes in the production and sales of high-quality power equipment, including power distribution equipment, electrical products, generators, charging piles, frequency converters, etc. It is widely used in residential, commercial and industrial fields.

3.How do you ensure the quality of your products?

We strictly adhere to international standards and quality management systems. All products undergo rigorous testing and inspection before leaving the factory. We also offer a product quality guarantee period to ensure that the products you purchase meet your expected performance.

4.Do you offer customization services?

Yes, we can provide customized services according to the specific needs of our customers. Whether it's product specifications, design, or functionality, our technical team can work with you to develop solutions that meet your requirements.

5.Can you print our brand on the product?

Yes, of course, we also do OEM to print client’s brand on the product
